HSFPX002 FPGA Module

HSFPX002 FPGA Module

SKU: NLFX1009

Features

  • FPGA: Artix XC7A200T in FBG676 package
  • DDR3: 1x8Gb DDR3 (MT41K1G8SN-125:A) & 2x8Gb DDR3 (MT41K512M16HA-125:A TR)
  • Flash memory: 1 Gb Quad SPI flash memory (MT25QL01GBBB)
  • 1 x 100MHz CMOS oscillator
  • 8 GTP lanes (up to 6.6 GT/s)
  • FTDI FT601 for FPGA and Host communication
  • Maximum IOs for user-defined purposes
  •   —FPGA – 96 IOs

Applications

  • Product Prototype Development
  • Accelerated computing integration
  • Memory Intensive FPGA development
  • Data Acquisition
  • Educational tool for Schools and Universities

Request For Quote

HSFPX002 is an easy to use FPGA module featuring the Xilinx Artix 7 FPGA with total size of 24Gb DDR3 SDRAM. This board contains the Xilinx XC7A200T– FBG676 FPGA. This board features an Edge Rate® Rugged High-Speed Male connector, so this board works with the carrier boards (like Numato Lab’s HSFPX00X carrier board) that feature Edge Rate® Rugged High-Speed female connectors. This board has the FT601 IC for the configuration and communication between FPGA and USB host.
Features

  • FPGA: Artix XC7A200T in FBG676 package
  • DDR3: 1x8Gb DDR3 (MT41K1G8SN-125:A) & 2x8Gb DDR3 (MT41K512M16HA-125:A TR)
  • Flash memory: 1 Gb Quad SPI flash memory (MT25QL01GBBB)
  • 1 x 100MHz CMOS oscillator
  • 4x Edge Rate® Rugged High-Speed Male connector
  • 8 GTP lanes (up to 6.6 GT/s)
  • FTDI FT601 for FPGA and Host communication
  • Onboard voltage regulators for single power rail operation
  • 1 Bi-color LED for custom use
  • Maximum IOs for user-defined purposes
  •   —FPGA – 96 IOs

Applications

  • Product Prototype Development
  • Accelerated computing integration
  • Memory Intensive FPGA development
  • Data Acquisition
  • Educational tool for Schools and Universities

General FAQs

Specifications

Attribute Value
FPGA

Configuration Options

JTAG

Memory

Non-Volatile Configuration Storage

1 Gb flash memory

Primary Clock Frequency

Number Of GPIOs (Max)

Sample Code

Sample Code

HSFPX002 MicroBlaze HelloWorld Sample ProjectDownload
HSFPX002 DDR3 Sample ProjectDownload
HSFPX002 FMC GPIO Sample ProjectDownload
HSFPX002 FT601 Master Sample ProjectDownload
HSFPX002 PCIe PIO Sample ProjectDownload
HSFPX002 SMA Sample ProjectDownload
