Telesto MAX10 FPGA Module

$299.00$399.00

Telesto is an easy to use FPGA Module featuring Intel (formerly Altera) MAX 10 FPGA. The MAX 10 FPGAs come with dual embedded NOR Flash, with almost instant-on functionality hence eliminating the need for external configuration memory. The dual configuration flash on MAX 10 allows users to store and dynamically switch between two bitstreams on a single chip. They also feature integrated Analog-to-Digital Converters (ADCs). Telesto is pin compatible with Saturn Spartan 6 FPGA Module, Neso Artix 7 FPGA Module , Skoll Kintex 7 FPGA Module as well as Styx Zynq FPGA Module and offers a seamless upgrade path. The high speed USB 2.0 provides fast and easy configuration download to the built-in flash via JTAG using OpenOCD. No programmer or special downloader cable is needed to download the bitstream to the board.

Applications

  • Product Prototype Development
  • Accelerated computing integration
  • Development and testing of custom embedded processors
  • Signal Processing
  • Communication devices development
  • Educational tool for Schools and Universities
  • System monitoring
Clear
SKU: NLFA1001 Category:

Description

Telesto is an easy to use FPGA Module featuring Intel (formerly Altera) MAX 10 FPGA. The MAX 10 FPGAs come with dual embedded NOR Flash, with almost instant-on functionality hence eliminating the need for external configuration memory. The dual configuration flash on MAX 10 allows users to store and dynamically switch between two bitstreams on a single chip. They also feature integrated Analog-to-Digital Converters (ADCs). Telesto is pin-compatible with Saturn Spartan 6 FPGA Module, Neso Artix 7 FPGA Module, Skoll Kintex 7 FPGA Module as well as Styx Zynq FPGA Module and offers a seamless upgrade path. The high-speed USB 2.0 provides fast and easy configuration download to the built-in flash via JTAG using OpenOCD. No programmer or special downloader cable is needed to download the bitstream to the board.

Features

    • Pin compatible with Saturn Spartan 6 FPGA ModuleNeso Artix 7 FPGA ModuleSkoll Kintex 7 FPGA Module and Styx Zynq FPGA Module and offers a seamless upgrade path
    • Device: MAX 10 FPGA (10M50DA/10M16DA, Dual Supply, F484 package and Speed Grade: -C8)
    • DDR3: 2Gb DDR3 (MT41J128M16HA-125:K or equivalent)
    • Internal Flash Memory
    • 100MHz LVDS oscillator
    • On-board voltage regulators for single power rail operation
    • FPGA configuration via JTAG and USB
    • Maximum IOs for user-defined purposes
      –FPGA – 150 IOs
      –Analog Inputs – 8 IOs
    • All user IOs are length matched and can be used as differential pairs

Applications

    • Product Prototype Development
    • Accelerated computing integration
    • Development and testing of custom embedded processors
    • Signal Processing
    • Communication device development
    • Educational tool for Schools and Universities
    • System monitoring

Telesto Altera MAX10 FPGA Board - Header pinout diagram

Additional information

Weight 0.8 lbs
Dimensions 5.00 x 3.00 x 1.00 in
FPGA Device

10M16DAF484, 10M50DAF484

Memory

Number Of GPIOs (Max)

158

Configuration Options

JTAG, USB

Primary Clock Frequency

Host Interface

USB 2.0

Downloads

User Manual
Driver for Telesto
View/Download 3D Model (STEP)

Knowledge Base

Programming Telesto using OpenOCD
