Tagus – Artix 7 PCI Express Development Board

$749.95

Tagus is an easy to use FPGA Development Board featuring Xilinx Artix-7 FPGA with x1 PCIe interface, Trusted Platform Module (ATXXXXXX) , Dual SFP+ cages, and 2Gb DDR3 SDRAM. This board features Xilinx XC7A200T– FBG484I FPGA. The board features Low Pin Count (LPC) high-speed FMC connector conforming to ANSI/VITA 57.1 Standard for the purpose of adding additional features to the board by using custom or commercial off-the-shelf daughter boards.

Features

  • FPGA: Artix-7 XC7A200T in -2 FBG484I package
  • 1 lane PCIe Gen2.0(5.0GT/s)
  • DDR3: 2Gb DDR3 (MT41J128M16HA-125:K or equivalent)
  • 128 Mb QSPI flash memory (N25Q128A13ESE40E) for Configuration and optional data storage
  • USB to UART serial converter
  • 1 x 100MHz CMOS oscillator
  • Maximum 68 IOs for user-defined purposes on ANSI/VITA 57.1 Standard compliant FMC LPC connector
  • 1x GTP lanes upto 6.6Gbps on ANSI/VITA 57.1 Standard compliant FMC LPC connector
  • 1 RGB LED for custom use
  • 1x Trusted Platform Module (ATXXXXXX )
  • Dual SFP+ Cages
  • MicroSD adapter for bulk data storage
  • Onboard voltage regulators for single power rail operation
  • Can be powered from PCIe slot or from an external power supply
  • JTAG header for programming and debugging
  • All differential pairs are length matched on the board

In stock

SKU: NLFX1005 Category:

Description

Tagus is an easy to use FPGA Development Board featuring Xilinx Artix-7 FPGA with x1 PCIe interface, Trusted Platform Module (ATXXXXXX) , Dual SFP+ cages, and 2Gb DDR3 SDRAM. This board features Xilinx XC7A200T– FBG484I FPGA. The board features Low Pin Count (LPC) high-speed FMC connector conforming to ANSI/VITA 57.1 Standard for the purpose of adding additional features to the board by using custom or commercial off-the-shelf daughter boards.

Features

  • FPGA: Artix-7 XC7A200T in -2 FBG484I package
  • 1 lane PCIe Gen2.0(5.0GT/s)
  • DDR3: 2Gb DDR3 (MT41J128M16HA-125:K or equivalent)
  • 128 Mb QSPI flash memory (N25Q128A13ESE40E) for Configuration and optional data storage
  • USB to UART serial converter
  • 1 x 100MHz CMOS oscillator
  • Maximum 68 IOs for user-defined purposes on ANSI/VITA 57.1 Standard compliant FMC LPC connector
  • 1x GTP lanes upto 6.6Gbps on ANSI/VITA 57.1 Standard compliant FMC LPC connector
  • 1 RGB LED for custom use
  • 1x Trusted Platform Module (ATXXXXXX )
  • Dual SFP+ Cages
  • MicroSD adapter for bulk data storage
  • Onboard voltage regulators for single power rail operation
  • Can be powered from PCIe slot or from an external power supply
  • JTAG header for programming and debugging
  • All differential pairs are length matched on the board

Applications

  • Parallel Processing and Accelerators
  • Product Prototype Development
  • Development and Testing of custom embedded processors
  • Signal Processing
  • Communication Devices Development
  • Data Acquisition
  • Educational tool for Schools and Universities

Additional information

Weight 1.2 lbs
FPGA

Configuration Options

JTAG, USB

Memory

Number Of GPIOs (Max)

68

Non-Volatile Configuration Storage

N25Q128A13ESE40E

Total Number of GTP

4 (1x PCIe x1, 1x FMC LPC, 2x SFP+)

Differential Pairs Length Matched

Yes

Communication

x1 PCIe, USB-RS232

Primary Clock Frequency

Downloads

User Manual

Sample Code

Tagus PCI-Express x1 Test ProjectDownload
Tagus PCI-Express x1 Bus Mastering DMA TestDownload
