LM4550 AC’97 Stereo Audio Codec Expansion Module

$29.95

This module features LM4550, an AC’97 Rev 2.1 compliant audio codec which enables producing and recording high quality stereo audio. This  module is designed to be used with Numato Lab’s FPGA/Microcontroller boards featuring a 2×6 pin  Expansion connector. It can also be used with other boards and connector types by using manual wiring. This product is compatible with many Numato Lab’s FPGA boards.
Features

  • One 2×6 pin Expansion connector
  • AC’97 Rev 2.1 compliant
  • 90 dB Dynamic Range
  • Stereo Headphone Amp With Separate Gain Control

Applications

  • Product Prototype Development
  • Audio Record/Playback Systems
  • Media players

In stock

SKU: EXPAUD003 Category:

Description

This module features LM4550, an AC’97 Rev 2.1 compliant audio codec which enables producing and recording high quality stereo audio. This  module is designed to be used with Numato Lab’s FPGA/Microcontroller boards featuring a 2×6 pin  Expansion connector. It can also be used with other boards and connector types by using manual wiring. This product is compatible with many Numato Lab’s FPGA boards.

Features

  • One 2×6 pin Expansion connector
  • AC’97 Rev 2.1 compliant
  • 90 dB Dynamic Range
  • Stereo Headphone Amp With Separate Gain Control
  • Dimension: 50mm x 46mm

Applications

  • Product Prototype Development
  • Audio Record/Playback Systems
  • Media players

Additional information

Weight 0.10 lbs
Dimensions 5.00 x 3.00 x 2.00 in
Audio Codec

AC97

Audio Out

Analog

Codec Device

LM4550

Downloads

User Manual

Sample Code

NameLanguage/TechnologyIDEHardware Modules Required
LM4550 AC97 AudioVerilogXilinx ISELM4550 AC97 Expansion Module
